Evolution Pro2
Consultation
Evolution Pro2

Specification and grades Evolution Pro2

Evolution Pro2 Basic Specification

«Evolution Pro2» karaoke system
Pre-installed track database
containing Pro and Lite format tracks (includes all updates existing at the time of buying).
Audio cables
TRS 6.3-TRS 6.3 balanced stereo 2 шт.
Network cable
HDMI cable
Linux Evolution Operating System
EvoСlub Admin Series
EvoСlub Guest Series
EvoСlub User Series

Evolution Pro2 specification

Evolution Pro2
front panel

Supported file formats
Video
MOV, AVI, MPEG, MP4, MKV
Audio
WAV, OGG, MP3
Graphic
PNG, JPG
Karaoke
EK2
Audio
Input audio signal standards
Analogue: TRS 6.3-TRS 6.3 balanced stereo – 3 inputs
Output audio signal standards
Analogue: TRS 6.3-TRS 6.3 balanced stereo – 3 outputs
Digital signal sampling rate
32 – 192 kHz
Analogue signal sampling rate
8 – 192 kHz
DAC/ADC bits number
24 bit
Number of microphone inputs
2
Possibility of microphone signal level adjustment
Available
USB
Number
8
Connector type
USB А
Version
2.0, 3.0
Supported USB storage devices
USB flash memory, USB HDD, USB Card Readers
File system
FAT32, NTFS
Inputs
Number of microphone inputs
2
Possibility of microphone signal level adjustment
Available
Microphone input maximum gain
46 dB
Maximum input amplitude
+1.5 dBV (1.2 V RMS)
Input signal-to-noise ratio
113 dB
Dynamic range
113 dB
Harmonic distortions + noise
0,0006 %
Bandwidth (+/- 0.5 dB)
80 Hz — 80 kHz
Crosstalk
–130 dB
Input impedance
4,7 kOhm
Audio ADC
AKM AK5385В
Outputs
Input signal-to-noise ratio
108 dB
Dynamic range
109 dB
Harmonic distortions + noise
0,0023 %
Bandwidth (+/- 0.5 dB)
20 Hz – 80 kHz
Crosstalk
–105 dB
Output impedance
4,7 kOhm
Audio DAC
АК4358
Video
Output video signal standards
HDMI, DVI, VGA, Composite (5 шт.)
Display maximum resolution
1920*1080″, 60 Hz (1080 р)
System
Operating system
Linux Evolution
Total HD storage capacity
2 TB
LAN (Ethernet) connector
Available
Ethernet bitrate
100 Mbit/s
Wi-Fi
No
SATA 3.0
Available
Other characteristics
Power supply
~220 V ±10% 50 Hz ±1 Hz
Power consumption
550 Вт
Shipping box dimensions (WxHxD) mm
507×255×470
Device dimensions (WxHxD) mm
420×145×300
Net weight
10,8 kg
Gross weight
12,5 kg
Operating temperature range
+5…+40 ºC
Humidity
10–80%
$4,300
Without VAT
Order
